MIL-DTL-40082C
TABLE II Visual examination of the end item. - Continued
EXAMINE
DEFECT
Malformed, damaged, warped, twisted, distorted, bent out of shape, or
otherwise impaired to an extent affecting durability or serviceability.
Not clean, i.e., scale, corrosion, bark, rust, or sludge deposits.
Quality of
Not fabricated from specified material.
Metal
Surface spotted or open grained, i.e., scale, corrosion, bark, rust, or sludge
deposits.
Identification
Missing, incorrect, illegible, or text incomplete.
Marking
Words "U.S. Property" or "U.S. Prop" in characters less than 1/8 inch high.
Finish
Surfaces not ground as required.
4.2.4 Examination for end item dimensions. Any dimension that is not within specified
tolerances shall be classified as a critical defect.
4.2.5 Hardness testing of the end item. Testing of the completely fabricated hub or die shall
be performed in accordance with guidelines specified in 3.3.5 and ASTM E18. Results shall be
reported to the nearest whole number. Care should be exercised to limit hardness readings to
areas where indentations will not damage the heraldic design.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as
specified in the contract or order (see 6.2). When actual packaging of materiel is to be
performed by DoD personnel, these personnel need to contact the responsible packaging
activity to ascertain requisite packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activity within the Military
Department or Defense Agency, or within the Military Department's System Command.
Packaging data retrieval is available from the managing Military Department's or Defense
Agency's automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful
but is not mandatory.)
6.1 Intended use. The hubs and dies covered by this specification are intended to be
loaned to contractors for extracting their working dies in the manufacture of heraldic items.
This specification also covers master dies to be retained by the Government and used for
replacement of Government hubs.
6.2 Acquisition requirements. Acquisition documents should specify the following:
5
