MIL-DTL-14645C
TABLE II. Testing of components. - continued
RESULTS
COMPONENT
CHARACTERISTIC
RQM'T
TEST METHOD
REPORTED AS
AATCC-8, 1/
crocking
3.3.1.3
pass or fail
Synthetic metallic
MIL-E-17568, 1/
embroidery yarn
material identification
3.3.3.1
pass or fail
ASTM-D1907, 1/
denier
3.3.3.1
pass or fail
uniformity of ribbon
around core
3.3.3.1
visual
pass or fail
Rayon or polyester
ASTM-D276; 1/
embroidery yarn
material identification
3.3.3.2
pass or fail
ply
3.3.3.2
visual
pass or fail
ASTM-D1907, 1/
denier
3.3.3.2
pass or fail
presence of sulfur
3.3.3.2
pass or fail
1/
colorfastness to:
5622, 1/
wet dry-cleaning
3.3.3.2
pass or fail
5662, 1/
light
3.3.3.2
pass or fail
1/ Unless otherwise specified, a contractor's certification of compliance may be accepted as evidence of
conformance.
4 3.2 Visual examination of the end item. Defects found during this examination shall be
classified according to Table III. The sample unit for this examination shall be one finished pair
of shoulder marks. Normal inspection distance for workmanship shall be 18 to 24 inches with
illumination equal to average daylight and arranged so as to avoid as much reflected light as
possible. Defects designated by an asterisk (T) shall be classified as major when seriously
affecting appearance or serviceability and minor when affecting appearance or serviceability but
not seriously.
TABLE III Visual examination of the end item.
EXAMINE
DEFECT
CLASSIFICATION
MAJOR
(T)
MINOR
Laminated cloth
Bubbles and/or puckering visible on shell
fabric before or after dry cleaning. . . . . . . .
X
W
Fusible cloth
Material not as specified
Shell fabrics
Material not as specified. . . . . . . . . . . . . . . . .
X
Manufacturing defect(s) such as hole, float,
W
broken end or pick, slub, lump, knot, streak
Design
Any shift affecting appearance. . . . . . . . . . . .
X
Not in accordance with cartoon or drawing. . .
X
Embroidered device
Missing, incomplete, wrongly positioned, or
and stripe
distorted. . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Stripe does not extend beyond creased line
when applicable
X
10
