MIL-DTL-41819/7L
OVERALL WIDTH
DASH
(STAR POINT TO
USER
NO.
TYPE STAR
CONFIGURATION
HEIGHT
STAR POINT)
-18
Silver (matte)
Quadruple
5/16"
1-3/16"
A, N, AF, MC, CG
-19
Gold (matte)
Single
5/16"
5/16"
A, N, AF, MC, CG
-20
Gold (matte)
Double
5/16"
19/32"
A, N, AF, MC, CG
-21
Gold (matte)
Triple
5/16"
29/32"
A, N, AF, MC, CG
-22
Gold (matte)
Quadruple
5/16"
1-3/16"
A, N, AF, MC, CG
MATERIAL: 85/15 Rich-Low Brass or 95/5 Gilding Metal
FINISH:
-1, -5, -6, -7, -14: Copper Flashed (Rich-Low Brass only), Oxidized, Relieved
-2, -3, -8, -9, -10: Nickel Plated, Mirror-like Polished, and shall match The Institute of
Heraldry Metal Finish Chip Number 16
-4, -11, -12, -13: Gold Plated, Mirror-like Polished, and shall match TIOH Metal Finish
Chip Number 6.
-15 thru -18: Nickel Plated, Matte Finished, and shall match TIOH Metal Finish Chip
Number 17.
-16 thru -22: Gold Plated, Matte Finished, and shall match TIOH Metal Finish Chip
Number 7.
THICKNESS:
-1, -2, -5 thru -10 (3/16 inch stars): 1/16 inch ± 1/64 inch
-3, -4, -11 thru -22 (5/16 inch stars): 5/64 inch ± 1/64 inch
NOTES:
1. The height and width measurements (shown on the table on page 1) are REF and
refer to measurements taken from the Government furnished hub or die.
2. Attaching device for all configurations shall be staple type prong or U-wire centered
on the back of the star or star grouping.
3. -5 thru -13, -16 thru -18, and -20 thru -22 are optional items and were developed for
commercial sale.
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with
vertical lines to indicate where changes from the previous issue were made. This was
done as a convenience only and the Government assumes no liability whatsoever for any
inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
Custodians:
Preparing activity:
Army - IH
Army - IH
Air Force - 11
(Project No. 8455-2005/017)
Navy - NU
2 of 3
