INCH-POUND
MIL-DTL-41819/7L
20 May 2005
SUPERSEDING
MIL-DTL-41819/7K
13 June 2003
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, STAR
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and MIL-DTL-41819.
The various stars and star configurations addressed by this specification sheet are listed in
the table below:
OVERALL WIDTH
DASH
(STAR POINT TO
USER
NO.
TYPE STAR
CONFIGURATION
HEIGHT
STAR POINT)
-1
Bronze
Single
3/16"
3/16"
A, N, AF, MC, CG
-2
Silver (polished)
Single
3/16"
3/16"
A, N, AF, MC, CG
-3
Silver (polished)
Single
5/16"
5/16"
A, N, AF, MC, CG
-4
Gold (polished)
Single
5/16"
5/16"
N, AF, MC, CG
-5
Bronze
Double
3/16"
13/32"
A, N, AF, MC, CG
-6
Bronze
Triple
3/16"
5/8"
A, N, AF, MC, CG
-7
Bronze
Quadruple
3/16"
13/16"
A, N, AF, MC, CG
-8
Silver (polished)
Double
3/16"
13/32"
A, N, AF, MC, CG
-9
Silver (polished)
Triple
3/16"
5/8"
A, N, AF, MC, CG
-10
Silver (polished)
Quadruple
3/16"
13/16"
A, N, AF, MC, CG
-11
Gold (polished)
Double
5/16"
19/32"
N,
MC, CG
-12
Gold (polished)
Triple
5/16"
29/32"
N,
MC, CG
-13
Gold (polished)
Quadruple
5/16"
1-3/16"
N,
MC, CG
-14
Bronze
Single
5/16"
5/16"
AF
-15
Silver (matte)
Single
5/16"
5/16"
A, N, AF, MC, CG
-16
Silver (matte)
Double
5/16"
19/32"
A, N, AF, MC, CG
-17
Silver (matte)
Triple
5/16
29/32"
A, N, AF, MC, CG
AMSC N/A
1 of 3
FSC 8455
