INCH-POUND
MIL-DTL-3628/98C
23 FEBRUARY 2006
SUPERSEDING
MIL-DTL-3628/98B
10 September 2001
DETAIL SPECIFICATION SHEET
BADGE, OCCUPATIONAL, SERVICES, AIR FORCE
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-3628 listed in that issue of the Department of Defense Index
of Specifications and Standards (DoDISS) specified in the solicitation.
DASH NO.
-1: Basic, Regular Size
-4: Basic, Mid Size
-2: Senior, Regular Size
-5: Senior, Mid Size
-3: Master, Regular Size
-6: Master, Mid Size
MATERIAL: Red Brass
FINISH: Nickel Plated, Mirror-like Polished and shall match The Institute
of Heraldry (TIOH) Metal Finish Chip Number 16.
DIMENSIONS:
HEIGHT (overall):
-1: 3/4 inch (REF)
-2: 1-1/16 inches (REF)
-3: 1-1/16 inches (REF)
-4: 5/8 inch (REF)
-5: 7/8 inch (REF)
-6: 7/8 inch (REF)
AMSC N/A
1 of 2
FSC 8455
