MIL-DTL-3628/82D
DIMENSIONS:
PENDANT:
HEIGHT (Overall): 1-5/16 inches (REF)
WIDTH (Overall): 1-1/8 inches (REF)
THICKNESS: (Edge): 0.100 inch + 0.010 inch
SUSPENSION BAR:
HEIGHT (Overall): 9/32 inch (REF)
WIDTH (Overall): 1-1/2 inches (REF)
THICKNESS (Edge): 0.075 inch + 0.010 inch
EPOXY: Epoxy resin shall be applied to the Badge Qualification as indicated above,
and shall match TIOH Hard Enamel Color Chip Numbers listed below. Hard cloisonné
enamel may be used in lieu of epoxy. If hard cloisonné enamel is used, the required
base material shall be Gilding Metal 95/5 (UNS Alloy C-210).
TIOH HARD ENAMEL COLOR
CHIPS
COLOR
CHIP NUMBER
Black
#26
White
#28
ATTACHING DEVICE AND LUGS:
1. The attaching device shall be prong and clutch type.
2. The prongs shall be located on the horizontal centerline of the suspense bar
equidistant from each end and 1-5/16 inches apart.
3. The links shall be fabricated from gold plated wire with a nominal diameter of 0.050
inch. The overall dimension of the links shall be 1/4 inch + 1/64 inch in length and 7/32
inch + 1/64 inch in width.
4. Jump rings shall have a nominal diameter of 0.035 inch and shall be made from gold plated
wire with a nominal diameter of 0.050 inch.
-Suspension bar jump rings shall be soldered to the bottom of the suspension bar at a location
11/32 inch in from the outside edge of the rim (as shown).
-Pendant bar jump rings shall be soldered centered in the top inside corner of the shield
(as shown).
NOTE:
The term (REF) refers to the measurements taken from the Government furnished hub or die.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
