INCH-POUND
MIL-DTL-3628/64H
13 November 2006
SUPERSEDING
MIL-DTL-3628/64G
11 June 2001
DETAIL SPECIFICATION SHEET
BADGE, OCCUPATIONAL, SPACE/MISSILE, AIR FORCE
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-3628.
BASIC
SENIOR
MASTER
DASH NO.
-1: Basic, Regular Size (AF, A) -4: Basic, Mid Size (AF, A)
-2: Senior, Regular Size (AF, A) -5: Senior, Mid Size (AF, A)
-3: Master, Regular Size (AF, A) -6: Master, Mid Size (AF, A)
MATERIAL: Red Brass or Nickel Silver
FINISH: Nickel plated (Red Brass only), Mirror-like Polished and shall match The Institute
of Heraldry (TIOH) Metal Finish Chip Number 16.
DIMENSIONS:
HEIGHT (overall):
-1: 7/8 inch (REF)
-2: 1-1/8 inches (REF)
-3: 1-3/16 inches (REF)
-4: 21/32 inch (REF)
AMSC N/A
1 of 2
FSC 8455
