INCH-POUND
MIL-DTL-3628/56F
4 June 2014
SUPERSEDING
MIL-DTL-3628/56E
15 November 1996
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, OFFICER IN CHARGE (AFLOAT), ENLISTED PERSONNEL
U.S. COAST GUARD
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3628.
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL (-1 and -2): Red Brass 85/15 (UNS Alloy No.C-230) or Nickel Silver 65/35
(UNS Alloy C-752)
FINISH: (-1 and -2) Nickel Plated (C-230 Only), Silver Plated, Oxidized, Buffed Relieved, Matte
Finish and shall match The Institute of Heraldry Metal Finish Chip Number 14.
DIMENSIONS:
HEIGHT (Overall):
-1: 1-5/8 inches (REF)
-2: 13/16 inch (REF)
WIDTH (Overall):
-1: 1-7/16 inches (REF)
-2: 23/32 inch (REF)
THICKNESS (At thickest point of the shield):
AMSC N/A
Page 1 of 2
FSC 8455
