INCH-POUND
MIL-DTL-3628/51H
15 November 2008
SUPERSEDING
MIL-DTL-3628/51G
15 November 1996
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, PATHFINDER, ARMY
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification sheet and the latest issue of MIL-DTL-3628.
MATERIAL:
DASH NO.
-1, -3: Gilding Metal
-1: Regular Size
-2: Red Brass or Gilding Metal
-2: Regular Size, Subdued
-3: Dress Miniature Size
DIMENSIONS:
HEIGHT (overall):
-1, -2: 1-3/16 inches (REF)
-3: 11/16 inch (REF)
WIDTH (overall):
-1, -2: 1-1/2 inches (REF)
-3: 7/8 inch (REF)
THICKNESS (at thickest point of torch):
-1, -2: 0.100 inch + 0.010 inch
-3: 0.075 inch + 0.010 inch
AMSC N/A
Page 1 of 3
FSC 8455
