INCH-POUND
MIL-DTL-3628/31H
19 February 2010
SUPERSEDING
MIL-DTL-3628/31G
29 April 2005
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, SENIOR PARACHUTIST, NAVY AND MARINE CORPS
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3628.
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Not less than 85/15 Rich-Low Brass
FINISH: 24K Gold Plated, Mirror-like Polished and shall match The Institute of Heraldry
(TIOH) Metal Finish Chip Number 6.
DIMENSIONS:
HEIGHT (overall):
-1: 13/16 inch (REF)
-2: 13/32 inch (REF)
WIDTH (overall):
-1: 2-3/4 inches (REF)
-2: 1-3/8 inches (REF)
THICKNESS (at thickest point of wing):
-1: 0.120 inch + 0.005 inch
-2: 0.085 inch + 0.005 inch
AMSC N/A
Page 1 of 2
FSC 8455
