INCH-POUND
MIL-DTL-3628/265
31 March 2015
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, NATIONAL GUARD CHIEF S 50 MARKSMANSHIP,
RIFLE AND PISTOL CHAMPIONSHIPS, PENDANT AND SUSPENSION BAR
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the issue of MIL-DTL-3628.
MATERIAL: PENDANT AND SUSPENSION BAR: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: PENDANT AND SUSPENSION BAR: 24K Gold Plated, Matte Finish, Polished
Highlights and shall match the Institute of Heraldry Metal Finish Chip Number 8.
DIMENSIONS:
HEIGHT (Overall):
ASSEMBLED: 2 Inches (REF)
PENDANT: 1-15/32 inches (REF)
SUSPENSION BAR (Without lugs): 3/8 inch (REF)
WIDTH (Overall):
PENDANT: 1-9/32 inches (REF)
SUSPENSION BAR: 1-15/32 inches (REF)
THICKNESS:
PENDANT: 0.109 + .010 inch
SUSPENSION BAR: 0.103 + .010 inch
AMSC N/A
Page 1 of 2
FSC 8455
