MIL-DTL-3628/265
ATTACHING DEVICE:
1. The attaching device shall be prong and flat ball type clutch.
2. The prongs shall be located on the horizontal center line of the suspension bar, equidistant
from each end and 1-11/32 inches + 1/32 inch apart.
NOTES:
1: The term (REF) refers to the measurements taken from the Government furnished
hub or die.
2: The links shall be gold plated with the option of using Nickel Silver as the base metal
3. The lugs are integral to the suspension bar and pendant.
Custodian:
Preparing activity:
Army - IH
Army - IH
Review activity:
(Project No. 8455-2015-257)
DLA - CT
NOTE: The activities listed above were interested in this document as of the date of this
document. Since organizations and responsibilities can change, you should verify the currency
of the information above using the ASSIST Online database at https://assist.dla.mil.
Page 2 of 2
