INCH-POUND
MIL-DTL-3628/24K
16 June 2014
SUPERSEDING
MIL-DTL-3628/24J
15 August 2009
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, COMBAT INFANTRYMAN, U.S. ARMY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the latest issue of MIL-DTL-3628.
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230) or Nickel Silver 65/35
(UNS Alloy No C752)
FINISH:
-1 thru -4, -9 thru -12, -17 thru -20:
FRAME: Soft Enameled, Nickel Plated (Red Brass only), Silver Plated, Oxidized,
Relieved, Matte Finish and shall match The Institute of Heraldry (TIOH) Metal Finish Chip
Number 14.
STAR(S): Silver Plated, Mirror-like Polished (when applicable).
-5 thru -8, -13 thru 16:
WREATH: Shaded, Gold Plated, Matte Finish and shall match TIOH Metal Finish
Chip Number 7.
AMSC N/A
Page 1 of 3
FSC 8455
