INCH-POUND
MIL-DTL-3628/23H
7 April 2014
SUPERSEDING
MIL-DTL-3628/23G
15 November 1996
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, EXPERT INFANTRYMAN, U. S. ARMY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3628.
LIGHT BLUE ENAMEL
MUSKET RAISED
DASH NO.
-1: Regular Size
-2: Miniature Size
-3: Dress Miniature Size
-4: Regular Size Subdued
MATERIAL: (-1 through -4): Red Brass 85/15 (UNS Alloy No. C-230), or Nickel Silver 65/35
(UNS Alloy C-752)
FINISH:
1: (-1 through -3): Red Brass 85/15 (UNS Alloy No. C-230) or Nickel Silver: Nickel Plated
(C-230 only), Silver Plated, Oxidized, Relieved, Matte Finish and shall match The Institute of
Heraldry (TIOH) Metal Finish Chip Number 14.
2: -4: Red Brass 85/15 (UNS Alloy No. C-230), Dull Flat Black and shall match TIOH
Metal Finish Chip Number 21.
DIMENSIONS:
HEIGHT (Overall):
-1, -4: 7/16 inch (REF)
-2: 3/8 inch (REF)
-3: 3/16 inch (REF)
AMSC N/A
Page 1 of 2
FSC 8455
