INCH-POUND
MIL-DTL-3628/21H
05 November 2012
SUPERSEDING
MIL-DTL-3628/21G
15 November 1996
DETAIL SPECIFICATION SHEET
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
BADGE, QUALIFICATION, BASIC, DRIVER AND MECHANIC, U.S. ARMY
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3628.
Pebbled Background
MATERIAL: Red Brass 85/15 (UNS Alloy No.C-230) or Nickel Silver 65/18 (UNS Alloy No.C-
752).
FINISH: Nickel Plated (C-230 only), Silver Plated, Oxidized, Buffed Relieved, Matte Finish
and shall match The Institute of Heraldry (TIOH) Metal Finish Chip Number 14 with reverse
and edges clean.
DIMENSIONS:
HEIGHT (Without lugs): 1 inch (REF)
WIDTH (Overall): 1 inch (REF)
THICKNESS: (At rim): 0.070 inch + 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
