INCH-POUND
MIL-DTL-3628/15M
14 February 2013
SUPERSEDING
MIL-DTL-3628/15L
22 January 1999
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, MARKSMANSHIP CLASPS EXPERT, SHARPSHOOTER
AND MARKSMAN, U.S. ARMY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3628.
Pebbled Background
DASH NO: BADGE CLASP TITLES
-1: Rifle
-11: Machine Gun
-2: Recoilless Rifle
-12: Rocket Launcher
-3: Auto-Rifle
-13: Submachine Gun
-4: Small Bore Rifle
-14: Grenade
-5: Bayonet
-15: Field Artillery
-6: Pistol
-16: A.A. Artillery
-7: Flame Thrower
-17: Mortar
-8: Small Bore Pistol
-18: Missile
-9: Tank Weapons
-19: Aeroweapons
-10: Carbine
MATERIALS:
BADGE CLASP: Red Brass 85/15 (UNS Alloy No.C-230) or Nickel Silver 65/35
(UNS Alloy C-752)
JUMP RINGS: Nickel Silver 65/35 (UNS Alloy C-752)
FINISH: Nickel Plated, (C-230 only) Silver Plated, Oxidized, Buffed Relieved, Matte Finish with
reverse and edges clean and shall match The Institute of Heraldry (TIOH) Metal Finish Chip
Number 14.
AMSC N/A
Page 1 of 2
FSC 8455
