INCH-POUND
MIL-DTL-11589/119G
24 August 2010
SUPERSEDING
MIL-DTL-11589/119F
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, PHILIPPINE DEFENSE
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Scarlet
HL
67111
7/32
5.6mm
Ground
Scarlet
HL
67111
1-3/8"
5/32
4.0mm
Ground
White
HA
67101
White
(35.0mm)
9/16*
14.2mm
Ground
Scarlet
HL
67111
HA 67101
5/32
4.0mm
Ground
White
HA
67101
7/32
5.6mm
Ground
Scarlet
HL
67111
1/32
0.8mm
Edge & Binder
Scarlet
HL
67111
*NOTE: Three five-pointed white stars, each star measuring 5/32 inch (4.0mm) in diameter and with 2 rays
pointed downward, shall be located in the center of the 9/16 inch (14.2mm) Scarlet stripe, to form an equilateral
triangle measuring 9/32 inch (7.1mm) on each side. The center of each star shall be located in the points of the
equilateral triangle. The triangular group of stars shall be formed either from a filling effect design or screen
printed at the option of the manufacturer. Each triangular design of white stars shall be 1-1/4 inches (31.8mm)
apart measured from center to center with a cutting mark (white thread) midway between each group of stars.
AMSC N/A
Page 1 of 2
FSC 8455
