MIL-DTL-11589/109E
COLOR PATTERN: MINIATURE SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Scarlet
HL
67111
1/16
1.6mm
Ground
Scarlet
HL
67111
1/32
0.8mm
Ground
White
HA
67101
9/64
3.6mm
Ground
Scarlet
HL
67111
11/16"
3/64
1.2mm
Ground
Ultramarine Blue
HS
67118
White
(17.5mm)
1/16
1.5mm
Ground
Scarlet
HL
67111
HA 67101
1/16
1.2mm
Ground
Ultramarine Blue
HS
67118
9/64
3.6mm
Ground
Scarlet
HL
67111
1/32
0.8mm
Ground
White
HA
67101
1/16
1.6mm
Ground
Scarlet
HL
67111
1/32
0.8mm
Edge & Binder
Scarlet
HL
67111
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical
lines to indicate where changes from the previous issue were made. This was done as a
convenience only and the Government assumes no liability whatsoever for any inaccuracies in
these notations. Bidders and contractors are cautioned to evaluate the requirements of this
document based on the entire content irrespective of the marginal notations and relationship to the
last previous issue.
