INCH-POUND
MIL-DTL-11589/109E
2 June 2010
SUPERSEDING
MIL-DTL-11589/109D
15 September 1995
DETAIL SPECIFICATION SHEET
RIBBON, NCO PROFESSIONAL MILITARY EDUCATION GRADUATE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and the latest issue of MIL-DTL-11589.
COLOR PATTERN: REGULAR SIZE
FINISH: MOIRÉ
TOTAL
WIDTH OF STRIPES
FUNCTION
COLOR & CABLE NUMBER
WIDTH
INCHES & METRIC
OF STRIPES
STRIPES
FILLING YARN
1/32
0.8mm
Edge & Binder
Scarlet
HL
67111
5/32
4.0mm
Ground
Scarlet
HL
67111
1/16
1.6mm
Ground
White
HA
67101
9/32
7.1mm
Ground
Scarlet
HL
67111
1-3/8"
3/32
2.4mm
Ground
Ultramarine Blue
HS
67118
White
(35.0mm)
1/8
3.2mm
Ground
Scarlet
HL
67111
HA 67101
3/32
2.4mm
Ground
Ultramarine Blue
HS
67118
9/32
7.1mm
Ground
Scarlet
HL
67111
1/16
1.6mm
Ground
White
HA
67101
5/32
4.0mm
Ground
Scarlet
HL
67111
1/32
0.8mm
Edge & Binder
Scarlet
HL
67111
AMSC N/A
Page 1 of 2
FSC 8455
