MIL-DTL-11132/24H
DEVICE:
HEIGHT (Overall): 1/2 inch (REF)
WIDTH (Overall): 1/8 inch (REF)
THICKNESS (Edge): 0.085 inch + 0.005 inch
ASSEMBLED (Thickest Point): 0.150 inch + 0.010 inch
EPOXY: Epoxy resin shall be applied to the insignia grade as indicated above, and shall match
TIOH Hard Enamel Color Chip Numbers listed below. Hard cloisonné enamel may be used in
lieu of epoxy. If hard cloisonné enamel is used, the required base material shall be Gilding
Metal 95/5 (UNS Alloy C-210).
TIOH HARD ENAMEL COLOR CHIPS
COLOR
CHIP NUMBER
Blue
#18
Red
#1
Light Blue
#30
ATTACHING DEVICE:
1. The device shall be secured to the base by two solid brass rivets 0.035 inch minimum
in diameter located on the vertical center line of the device.
2. Attaching device shall be prong and clutch type.
3. Prongs shall be attached on the horizontal center line, equidistant from each side and
7/8 inch + 1/32 inch apart.
NOTES:
1. The term (REF) refers to the measurements taken from the obverse Government furnished
hub or die.
2. The base may be rhodium plated with a mirror-like polished finish at the option of the
manufacture.
3. Acid test for the gold plated device shall not apply.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
Page 2 of 3
