INCH - POUND
MIL-DTL-41819/55
24 November 2014
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, NUCLEAR DETERRENCE OPERATIONS "N" DEVICE
U.S. AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-R-41819.
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Brass, Matte Finish and shall match the Institute of Heraldry Metal Finish Chip
Number 2
DIMENSIONS:
HEIGHT:
-1: 1/4 inch (REF)
-2: 1/8 inch (REF)
WIDTH:
-1: 1/4 inch (REF)
-2: 1/8 inch (REF)
THICKNESS:
-1: 0.057 inch ± 0.010 inch
-2: 0.044 inch ± 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
