NOT MEASUREMENT SENSITIVE
MIL-DTL-41819/40C
22 September 1997
SUPERSEDING
MIL-DTL-41819/40B
30 September 1996
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, LETTER "M"
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-41819 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
Dash No.
-1:
Regular Size
MATERIAL:
Red Brass or Gilding Metal
-2:
Miniature Size
FINISH: Copper Flash (Red Brass
only), Matte Finish
DIMENSIONS:
HEIGHT (Overall):
-1: 1/4 inch +
1/64 inch (0.64 cm + 0.04 cm)
-2: 1/8 inch +
1/64 inch (0.32 cm + 0.04 cm)
WIDTH (Overall):
-1: 1/4 inch +
1/64 inch (0.64 cm + 0.04 cm)
-2: 1/8 inch +
1/64 inch (0.32 cm + 0.04 cm)
THICKNESS (Thickest point):
0.055 inch + 0.005 inch (0.119 cm +
0.012 cm)
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
