NOT MEASUREMENT SENSITIVE
MIL-DTL-41819/39B
30 September 1996
SUPERSEDING
MIL-R-41819/39A
1 November 1994
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, KUWAIT LIBERATION, KINGDOM OF SAUDI ARABIA
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-41819 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass
DIMENSIONS:
HEIGHT (Overall): 11/32 inch (0.87 cm) (REF)
WIDTH (Overall):
3/8 inch (0.95 cm) (REF)
THICKNESS (At thickest point): 0.045 inch + 0.005 inch - 0 inch (0.114
cm + 0.012 cm - 0 cm)
FINISH:
Gold Plated, Matte Finish, Polished Highlights And Shall Match
TIOH Metal Finish Chip Number 8.
NOTES:
1. The term (REF) refers to the measurements taken from the
Government furnished hub or die.
2. The attaching device shall be a staple type prong centered on the
reverse of the ribbon attachment.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
