NOT MEASUREMENT SENSITIVE
MIL-DTL-41819/38B
30 September 1996
SUPERSEDING
MIL-R-41819/38A
1 November 1994
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, DISTINGUISHED PISTOL SHOT, COAST GUARD
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-41819 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Gilding Metal
DIMENSIONS:
HEIGHT: 1/4 inch (0.64 cm) (REF)
WIDTH: 1/4 inch (0.64 cm) (REF)
THICKNESS (At Thickest Point): 0.080 inch + 0.005 inch (0.203 cm +
0.012 cm)
FINISH:
Hard Enameled, Gold Plated, Mirror-like Polished and shall match
TIOH Metal Finish Chip Number 6.
NOTES:
1. The term (REF) refers to the measurements taken from the
Government furnished hub or die.
2. Enameled color shall be black as indicated. The enamel color
shall conform to TIOH chip number 26 or the standard sample.
3. Epoxy resin (stoning epoxy) may be used in lieu of hard enamel at
the option of the manufacturer.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
