NOT MEASUREMENT SENSITIVE
MIL-DTL-41819/35B
30 September 1996
SUPERSEDING
MIL-R-41819/35A
1 November 1994
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, EXCELLENCE IN COMPETITION, RIFLEMAN, COAST GUARD
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-41819 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Gilding Metal or Red Brass
DASH NO.
-1:
Bronze, 1st Award
DIMENSIONS:
-2:
Silver, 2nd Award
HEIGHT: 3/16 inch (0.48 cm) (REF)
WIDTH: 1-3/16 inches (3.02 cm) (REF)
THICKNESS (At Thickest Point): 0.060 inch + 0.005 inch (0.152 cm +
0.012 cm)
FINISH:
-1:
Copper Flash (Red Brass Only), Lightly Oxidized, Relieved, Matte
Finish
-2:
Nickel Plated, Silver Plated, Oxidized, Relieved, Matte Finish
and shall match TIOH Metal Finish Chip Number 14.
NOTES:
1. The term (REF) refers to the measurements taken from the
Government furnished hub or die.
2. The attaching device shall be a staple type prong. The prong
shall be centered on the reverse side of the ribbon attachment.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
