NOT MEASUREMENT SENSITIVE
MIL-DTL-41819/32D
30 September 1996
SUPERSEDING
MIL-R-41819/32C
1 November 1994
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, LETTER "S"
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-41819 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass
DASH NO.
-1:
Silver
-2:
Bronze
FINISH:
-1:
Nickel Plated, Mirror-like Polished and shall match TIOH Metal
Finish Chip Number 16.
-2:
Oxidized, Relieved, Matte Finish and shall match TIOH Metal
Finish Chip Number 4.
DIMENSIONS:
HEIGHT (Overall): 1/4 inch + 1/64 inch (0.64 cm + 0.04 cm)
WIDTH (Overall): 1/4 inch + 1/64 inch (0.64 cm + 0.04 cm)
THICKNESS: 0.050 inch + 0.005 inch (0.127 cm + 0.012 cm)
NOTES:
1.
Ribbon attachment "S" shall be die cut.
2. Ribbon attachment Dash No. -1 is intended to be worn on the Navy
Rifle and Pistol Marksmanship ribbon. Ribbon attachment Dash No. -2 is
intended to be worn on the NOAA Science award.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
