NOT MEASUREMENT SENSITIVE
MIL-DTL-41819/30C
30 September 1996
SUPERSEDING
MIL-R-41819/30B
1 November 1994
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, AFROTC BRONZE CROSS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-41819 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass or Gilding Metal
FINISH:
Copper Flash (Red Brass only), Oxidized, Relieved, Matte Finish
DIMENSIONS:
HEIGHT (Overall): 3/16 inch (0.48 cm) (REF)
WIDTH (Overall): 3/16 inch (0.48 cm) (REF)
THICKNESS: 0.050 inch + 0.005 inch (0.127 + 0.012 cm)
NOTES:
1. The term (REF) refers to the measurements taken from the
Government furnished hub or die.
2. The attaching device shall be a staple type prong.
The prong
shall be centered on the reverse side of the cross.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
