NOT MEASUREMENT SENSITIVE
MIL-DTL-41819/29C
30 September 1996
SUPERSEDING
MIL-R-41819/29B
1 November 1994
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, AFROTC DRILL TEAM AND COLOR GUARD BARS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-41819 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Red Brass or Gilding Metal
DASH NO.
-1:
Drill Team Bar
DIMENSIONS:
-2:
Color Guard Bar
HEIGHT (Overall): 1/8 inch (0.32 cm) (REF)
WIDTH (Overall): 13/16 inch (2.06 cm) (REF)
THICKNESS (At Thickest Point): 0.050 inch + 0.010 inch - 0 (0.127 cm +
0.025 cm - 0)
FINISH:
Copper Flash (Red Brass only), Oxidized, Relieved, Matte Finish.
NOTES:
1. The term (REF) refers to the measurements taken from the
Government furnished hub or die.
2. The attaching device shall be two prongs. The prongs shall be
located on the reverse side of the ribbon attachment at the horizontal
center line of the bar equidistant from each end and 5/8 inch + 1/32 inch
(1.59 cm + 0.08 cm) apart.
AMSC N/A
FSC 8455
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
