INCH-POUND
3
MIL-DTL-41819/28E
0 June 2014
SUPERSEDING
MIL-DTL-41819/28D
10 August 2009
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, OPERATIONAL DISTINGUISHED DEVICE, U.S. COAST GUARD
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the latest issue of MIL-DTL-41819.
DASH NO:
-1: Basic, Regular Size
-2: Basic, Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230) or Nickel Silver 65/35
(UNS Alloy No C-752)
FINISH: Nickel Plated (C-230 only), Mirror-like Polished and shall match The Institute of
Heraldry Metal Chip Finish Number 16.
DIMENSIONS:
HEIGHT (Overall):
-1: 1/4 inch + 1/64 inch
-2: 1/8 inch (REF)
WIDTH (Overall):
-1: 1/4 inch + 1/64 inch
-2: 1/8 inch (REF)
THICKNESS (At thickest point):
-1: 0.060 inch + 0.005 inch
-2: 0.050 inch + 0.005 inch
AMSC N/A
Page 1 of 2
FSC 8455
