INCH-POUND
MIL-DTL-41819/25G
25 February 2013
SUPERSEDING
MIL-DTL-41819/25F
30 September 1996
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, TORCH, SROTC U.S. ARMY, AND U.S. AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the latest issue of MIL-R-41819.
DASH NO.
-1: Bronze
-2: Silver
-3: Gold
MATERIAL:
-1, -3: Red Brass 85/15 (UNS Alloy No.C-230) or Gilding Metal 95/5 (UNS Alloy C-210)
-2: Red Brass 85/15 (UNS Alloy No.C-230) or Nickel Silver 65/15 (UNS Alloy C-752)
FINISH:
-1: Cooper Flash (C-230 only) Oxidized, Relieved
-2: Nickel Plated (C-230 only), Mirror-like Polished and shall match The Institute of
Heraldry (TIOH) Metal Finish Chip Number 16.
-3: 24K Gold Plated, Mirror-like Polished and shall match TIOH Metal Finish Chip
Number 6
DIMENSIONS:
HEIGHT (Overall): 1/4 inch (REF)
WIDTH (Overall): 7/64 inch (REF)
THICKNESS (At thickest point): 0.045 0.005 inch
AMSC N/A
Page 1 of 2
FSC 8455
