INCH-POUND
MIL-DTL-41819/23F
25 February 2013
SUPERSEDING
MIL-DTL-41819/23E
30 September 1996
DETAIL SPECIFICATION SHEET
RIBBON ATTACHMENT, DATE BAR, REPUBLIC OF VIETNAM CAMPAIGN MEDAL
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the latest issue of MIL-R-41819.
M
ATERIAL: Red Brass 85/15 (UNS Alloy No.C-230)
FINISH: Nickel Plated, Mirror-like Polished and shall match The Institute of Heraldry Metal
Finish Chip Number 16.
DIMENSIONS:
HEIGHT (Overall): 13/64 inch (REF)
WIDTH (Overall): 19/32 (REF)
THICKNESS (At edge): 0.040 0.005 inch
ATTACHMENT DEVICE:
1. The attaching device shall be a staple type prong.
2. The prong shall be centered on the reverse side of the ribbon attachment.
NOTES:
The term (REF) refers to the measurements taken from the Government furnished hub
or die.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
AMSC N/A
Page 1 of 2
FSC 8455
