INCH-POUND
MIL-DTL-3943/46J
6 June 2007
SUPERSEDING
MIL-DTL-3943/46H
7 April 1999
DETAIL SPECIFICATION SHEET
DECORATION, EXCEPTIONAL CIVILIAN SERVICE AWARD, ARMY
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3943.
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Red Brass
FINISH: Gold Plated, Matte Finish, Polished Highlights and shall match The Institute of
Heraldry (TIOH) Metal Finish Chip Number 8.
DIMENSIONS:
HEIGHT (including lug):
-1: 1-19/32 inches (REF)
-2: 13/16 inch (REF)
DIAMETER:
-1: 1-1/2 inches (REF)
-2: 3/4 inch (REF)
THICKNESS (at thickest point):
-1: 0.145 inch + 0.010 inch
-2: 0.095 inch + 0.010 inch
AMSC N/A
1of 2
FSC 8455
