INCH-POUND
MIL-DTL-3943/38E
1 October 2007
SUPERSEDING
MIL-DTL-3943/38D
1 May 1997
DETAIL SPECIFICATION SHEET
DECORATION, AWARD FOR DISTINGUISHED ACHIEVEMENT IN SCIENCE, NAVY
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3943.
MATERIAL: Red Brass
FINISH: Gold Plated, Matte Finish and shall match The Institute of Heraldry (TIOH) Metal
Finish Chip Number 7.
DIMENSIONS:
HEIGHT (including lug): 1-21/32 inch (REF)
DIAMETER: 1-1/2 inch (REF)
THICKNESS (at thickest point): 0.160 inch + 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
