INCH-POUND
MIL-DTL-3943/370
13 April 2015
DETAIL SPECIFICATION SHEET
MEDAL, QUALIFICATION, EXPERT PISTOL, U.S. COAST GUARD
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3943.
MATERIAL: Red Brass 85/15 (UNS Alloy No.C-230)
FINISH: Brass, Oxidized, Buffed Relieved, and shall match The Institute of Heraldry Metal
Finish Chip Number 4.
DIMENSIONS:
HEIGHT (Excluding lug): 1-5/16 inches (REF)
WIDTH (Overall): 1-5/16 inches (REF)
THICKNESS (At edge): 0.100 inch + 0.010 inch
LUG:
1. Lug for shall be formed from 0.050 inch + 0.002 inch diameter brass wire and shall have an
outside diameter of 13/64 inch + 1/64 inch.
2. Lug shall be hard soldered to the top of the pendant.
AMSC N/A
Page 1 of 2
FSC 8455
