INCH-POUND
MIL-DTL-3943/124H
30 April 2014
SUPERSEDING
MIL-DTL-3943/124G
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, ACHIEVEMENT MEDAL FOR CIVILIAN SERVICE, U. S. ARMY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-3943.
Obverse
Blue #18
Reverse
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Gilding Metal 95/5 (UNS Alloy C-210)
FINISH: Epoxy resin, 24K Gold Plated Matte Finish, Polished Highlights and shall match
The Institute of Heraldry (TIOH) Metal Finish Chip Number 8.
DIMENSIONS:
HEIGHT (Including lug):
-1: 1-9/16 inches (REF)
-2: 3/4 inch (REF)
DIAMETER:
-1: 1-3/8 inches (REF)
-2: 5/8 inch (REF)
THICKNESS (At edge):
-1: 0.120 inch + 0.010 inch
-2: 0.075 inch + 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
