INCH-POUND
MIL-DTL-3943/122D
6 May 2013
SUPERSEDING
MIL-DTL-3943/122C
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, SURGEON GENERAL S EXEMPLARY SERVICE MEDAL,
U.S. PUBLIC HEALTH SERVICE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-3943.
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: 24K Gold Plated, Matte Finish, Polished Highlights and shall match The Institute of
Heraldry Metal Finish Chip Number 8.
DIMENSIONS:
HEIGHT (Including lug):
-1: 1-9/16 inch (REF)
-2: 25/32 inch (REF)
DIAMETER:
-1: 1-3/8 inch (REF)
-2: 11/16 inch (REF)
THICKNESS (At thickest point):
-1: 0.155 inch + 0.010 inch
-2: 0.100 inch + 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
