INCH-POUND
MIL-DTL-3943/118D
7 April 2014
SUPERSEDING
MIL-DTL-3943/118C
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, GOLD AWARD, DEPARTMENT OF COMMERCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-3943.
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Gold Plated, Matte Finish, Polished Highlights and shall match The Institute of Heraldry
Standard Metal Finish Chip Number 8.
DIMENSIONS:
HEIGHT (Including lug):
-1: 1-9/16 inches (REF)
-2: 9/16 inch (REF)
ASMC N/A
Page 1 of 2
FSC 8455
