INCH-POUND
MIL-DTL-3943/109F
30 April 2014
SUPERSEDING
MIL-DTL-3943/109E
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, NOAA ASSOCIATION OF COMMISSIONED OFFICERS AWARDS,
NATIONAL OCEANIC AND ATMOSPHERIC ADMINISTRATION
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-3943.
DASH NO.
-1: Engineering Award, Regular Size
-2: Engineering Award, Miniature Size
-3: Science Award, Regular Size
-4: Science Award, Miniature Size
-5: Junior Officer of the Year Award, Regular Size
-6: Junior Officer of the Year Award, Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Nickel Plated, Silver Plated, Oxidized, Relieved, Matte Finish and shall match The
Institute of Heraldry Standard Metal Finish Chip Number 14.
DIMENSIONS:
HEIGHT (Including lug):
-1, -3, -5: 1-3/8 inch (REF)
-2, -4, -6: 3/4 inch (REF)
THICKNESS (At edge):
-1, -3, -5: 0.100 inch + 0.010 inch
-2, -4, -6: 0.075 inch + 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
