INCH-POUND
MIL-DTL3943/108E
16 May 2014
SUPERSEDING
MIL-DTL3943/108D
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, JOINT SERVICE ACHIEVEMENT MEDAL, DEPARTMENT OF DEFENSE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the issue of MIL-DTL-3943.
OBVERSE
REVERSE
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Oxidized, Relieved, Matte Finish and shall match The Institute of Heraldry
Standard Metal Finish Chip Number 4.
DIMENSIONS:
HEIGHT (Including lug):
-1: 1-19/32 inch (REF)
-2: 25/32 inch (REF)
WIDTH (At widest point):
-1: 1-7/16 inch (REF)
-2: 23/32 inch (REF)
THICKNESS (At edge):
-1: 0.150 inch + 0.010 inch
-2: 0.110 inch + 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
