INCH-POUND
MIL-DTL-3943/107F
28 April 2014
SUPERSEDING
MIL-DTL-3943/107E
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, OUTSTANDING CIVILIAN CAREER SERVICE AWARD, U.S. AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this
specification sheet and the issue of MIL-DTL-3943.
OBVERSE
REVERSE
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Oxidized, Relieved, Matte Finish and shall match The Institute of Heraldry
Standard Metal Finish Chip Number 4.
DIMENSIONS:
HEIGHT (Including lug): 1-5/8 inch (REF)
DIAMETER: 1-1/2 inch (REF)
THICKNESS: 0.150 inch + 0.010 inch
DECORATION SET AND CASE: Decoration set shall consist of a regular size medal, a
service ribbon and a lapel button all packaged in a presentation case conforming to
MIL-C-14633, Type XVI with a Type XVI, Class 1 or 3 pad.
NOTES:
1. The term (REF) refers to the measurements taken from the Government furnished
hub or die.
2. The specification slash sheet for the ribbon for the pendant drape and for the service
ribbon is MIL-DTL-11589/292.
AMSC N/A
Page 1 of 2
FSC 8455
