INCH-POUND
MIL-DTL-3943/102E
5 May 2014
SUPERSEDING
MIL-DTL-3943/102D
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, ACHIEVEMENT MEDAL, U.S. ARMY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-3943.
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Oxidized, Relieved, Matte Finish and shall match The Institute of Heraldry
Standard Metal Finish Chip Number 4
DIMENSIONS:
HEIGHT (Including lug):
-1: 1-5/8 inch (REF)
-2: 7/8 inch (REF)
WIDTH (Overall):
-1: 1-1/2 inch (REF)
-2: 11/16 inch (REF)
THICKNESS (At thickest point):
-1: 0.150 inch + 0.010 inch
-2: 0.110 inch + 0.010 inch
AMSC N/A
Page 1 of 2
FSC 8455
