INCH-POUND
MIL-DTL-3943/100E
28 April 2014
SUPERSEDING
MIL-DTL-3943/100D
15 January 2008
DETAIL SPECIFICATION SHEET
DECORATION, ACHIEVEMENT MEDAL, U. S. AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3943.
OBVERSE
REVERSE
DASH NO.
-1: Regular Size
-2: Miniature Size
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: Nickel Plated, Silver Plated, Oxidized, Buffed Relieved and shall match The Institute of
Heraldry Standard Metal Finish Chip Number 14.
DIMENSIONS:
HEIGHT (Including lug):
-1: 1-9/16 inch (REF)
-2: 25/32 inch (REF)
WIDTH (Overall):
-1: 1-3/8 inch (REF)
-2: 11/16 inch (REF)
AMSC N/A
Page 1 of 2
FSC 8455
