MIL-DTL-3628/88C
DIMENSIONS:
PENDANT:
HEIGHT (Overall): 1-3/8 inches (REF)
THICKNESS: (Edge): 0.095 inch + 0.010 inch
SUSPENSION BAR:
HEIGHT (Overall): 11/32 inch (REF)
WIDTH (Overall): 1-9/32 inches (REF)
THICKNESS (Edge): 0.075 inch + 0.010 inch
DEVICE:
TARGET:
HEIGHT: 3/8 inch (REF)
WIDTH: 3/8 inch (REF)
THICKNESS: 0.050 inch + 0.005 inch
COAT OF ARMS:
HEIGHT: 5/8 inch (REF)
WIDTH: 3/8 inch (REF)
THICKNESS: 0.050 inch + 0.005 inch
EPOXY: Epoxy resin shall be applied to the Badge Qualification as indicated above,
and shall match TIOH Hard Enamel Color Chip Numbers listed below. Hard cloisonné
enamel may be used in lieu of epoxy. If hard cloisonné enamel is used, the required
base material shall be Gilding Metal 95/5 (UNS Alloy C-210).
TIOH HARD ENAMEL COLOR
CHIPS
COLOR
CHIP NUMBER
Blue
#18
White
#28
ATTACHING DEVICE AND LUGS:
1. The attaching device shall be prong and clutch type.
2. The prongs shall be located on the horizontal center line of the suspension bar
equidistant from each end and 1-1/4 inches + 1/32 inch apart.
3. Lugs for the suspension bar and pendant shall be equidistant from each end and 7/8 inch +
1/64 inch on center. The lugs shall be fabricated from bronze wire with a diameter of 0.050 inch
+ 0.005 inch.
4. Lugs shall be hard soldered to the pendant or bar.
5. Links shall be fabricated from bronze wire with a nominal diameter of 0.050 inch. The
overall dimension of the links shall be 1/4 inch + 1/64 inch in length and 7/32 inch + 1/64 inch in
width.
6. The target and coat of arms shall be superimposed and secured to the pendant in the
location shown using soft solder.
