INCH-POUND
MIL-DTL-3628/84C
14 July 2014
SUPERSEDING
MIL-DTL-3628/84B
15 November 1996
DETAIL SPECIFICATION SHEET
BADGE, QUALIFICATION, DISTINGUISHED PISTOL SHOT, U. S. AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3628.
MATERIAL:
PENDANT: Gilding Metal 95/5 (UNS Alloy No. C-210) or Red Brass 85/15
(UNS Alloy No.C-230)
SUSPENSION BAR: Red Brass 85/15 (UNS Alloy No. C-230) or Gilding Metal 95/5
(UNS Alloy No.C-210)
DEVICE: Gilding Metal 95/5 (UNS Alloy No.C-210)
FINISH:
PENDANT:
OBVERSE: 24K Gold Plated, Matte Finish, Polished Highlights and shall match The
Institute of Heraldry (TIOH) Metal Finish Chip Number 8.
REVERSE: 24K Gold Plated, Mirror-like Polish and shall match TIOH Metal Finish
Chip Number 6.
SUSPENSION BAR:
OBVERSE: 24K Gold Plated, Matte Finish, Polished Highlights and shall match TIOH
Metal Finish Chip Number 8.
AMSC N/A
Page 1 of 3
FSC 8455
