MIL-DTL-3628/79C
FINISH:
PENDANT:
-1 OBVERSE: Epoxy resin (Stoning epoxy), Brass, Oxidized, Buffed Relieved, Polished
Highlights and shall match The Institute of Heraldry (TIOH) Metal Finish Chip Number 5.
REVERSE: Highly Polished, Lacquered, Front, Back Edges.
-2 OBVERSE: Epoxy resin (Stoning epoxy), Nickel Plated, Silver Plated, Matte Finish,
Polished Highlights and shall match TIOH Metal Finish Chip Number 13, and Rim Highly
Polished.
REVERSE: Nickel Plated, Silver Plated, Mirror-like Polished, Lacquered Front, Back,
and Edges.
SUSPENSION BAR:
-1 OBVERSE: Brass, Oxidized, Buffed Relieved, Polished Highlights and shall match
TIOH Metal Finish Chip Number 5, and Rim Highly Polished.
REVERSE: Nickel Plated, Mirror-like Polished, Lacquered Front, Back, and Edges.
-2 OBVERSE: Nickel Plated, Silver Plated, Matte Finish, Polished Highlights and shall
match TIOH Metal Finish Chip Number 13, and Rim Highly Polished.
REVERSE: Nickel Plated, Silver Plated, Mirror-Like Polished Lacquered Front,
Back and Edges.
DIMENSIONS:
PENDANT:
HEIGHT (Overall): 1-7/16 inches (REF)
WIDTH (Overall): 1-23/64 inches (REF)
THICKNESS: (Edge): 0.085 inch + 0.010 inch
SUSPENSION BAR:
HEIGHT (Overall): 11/32 inch (REF)
WIDTH (Overall): 1-7/8 inches (REF)
THICKNESS (Edge): 0.075 inch + 0.010 inch
EPOXY: Epoxy resin shall be applied to the Badge Qualification as indicated above,
and shall match TIOH Hard Enamel Color Chip Numbers listed below. Hard cloisonné
enamel may be used in lieu of epoxy. If hard cloisonné enamel is used, the required
base material shall be Gilding Metal 95/5 (UNS Alloy C-210).
TIOH HARD ENAMEL COLOR
CHIPS
COLOR
CHIP NUMBER
Black
#26
White
#28
ATTACHING DEVICE AND LUGS:
1. The links shall be fabricated from copper wire for -1 and silver plated wire for -2 with a
nominal diameter of 0.050 inch. The overall dimension of the links shall be 1/4 inch + 1/64
inch in length and 7/32 inch + 1/64 inch in width.
