MIL-DTL-3628/78C
FINISH:
PENDANT:
-1 OBVERSE: Epoxy resin (Stoning epoxy), Brass, Oxidized, Buffed Relieved, Polished
Highlights and shall match The Institute of Heraldry (TIOH) Metal Finish Chip Number 5.
REVERSE: Highly Polished, Lacquered, Front, Back Edges.
-2 OBVERSE: Epoxy resin (Stoning epoxy), Nickel Plated, Silver Plated, Matte Finish,
Polished Highlights and shall match TIOH Metal Finish Chip Number 13, and Rim Highly
Polished.
REVERSE: Nickel Plated, Silver Plated, Mirror-like Polished Lacquered Front, Back, and
Edges.
SUSPENSION BAR:
-1 OBVERSE: Brass, Oxidized, Buffed Relieved, Polished Highlights and shall match
TIOH Metal Finish Chip Number 5, and Rim Highly Polished.
REVERSE: Nickel Plated, Mirror-like Polished, Lacquered Front, Back, and Edges.
-2 OBVERSE: Nickel Plated, Silver Plated, Matte Finish, Polished Highlights and shall
match TIOH Metal Finish Chip Number 13, and Rim Highly Polished.
REVERSE: Nickel Plated, Silver Plated, Mirror-Like Polished Lacquered Front,
Back and Edges.
DIMENSIONS:
PENDANT:
HEIGHT (Overall): 1-7/16 inches (REF)
WIDTH (Overall): 1-23/64 inches (REF)
THICKNESS: (Edge): 0.085 inch + 0.010 inch
SUSPENSION BAR:
HEIGHT (Overall): 11/32 inch (REF)
WIDTH (Overall): 1-7/8 inches (REF)
THICKNESS (Edge): 0.075 inch + 0.010 inch
EPOXY: Epoxy resin shall be applied to the Badge Qualification as indicated above,
and shall match TIOH Hard Enamel Color Chip Numbers listed below. Hard cloisonn�
enamel may be used in lieu of epoxy. If hard cloisonn� enamel is used, the required
base material shall be Gilding Metal 95/5 (UNS Alloy C-210).
TIOH HARD ENAMEL COLOR
CHIPS
COLOR
CHIP NUMBER
Black
#26
White
#28
ATTACHING DEVICE AND LUGS:
1. The links shall be fabricated from copper wire for -1 and silver plated wire for -2 with a
nominal diameter of 0.050 inch. The overall dimension of the links shall be 1/4 inch + 1/64
inch in length and 7/32 inch + 1/64 inch in width.
