MIL-DTL-3628/6G
DIMENSIONS:
HEIGHT (overall):
ASSEMBLED: 1-15/16 inches (REF)
PENDANT: 1-1/4 inches (REF)
SUSPENSION BAR: 9/16 inch (REF)
TARGET: 17/32 inch (REF)
WIDTH (overall):
PENDANT: 1-3/64 inches (REF)
SUSPENSION BAR (including balls): 1-1/2 inches (REF)
TARGET: 15/32 inch (REF)
THICKNESS:
PENDANT (at rim): 0.086 inch + 0.005 inch
SUSPENSION BAR (thickest point): 0.095 inch + 0.005 inch
TARGET: 0.035 inch + .002 inch
NOTES:
1. The term (REF) refers to the measurements taken from the Government furnished
hub or die.
2. Enameled areas shall be as indicated. The color shall conform to TIOH Enamel
Color Chip Numbers listed below.
COLOR
CHIP NUMBER
Black
26
White
28
3. Epoxy resin (stoning epoxy) may be used in lieu of hard enamel at the option of
manufacturer. Epoxy resin shall be smooth and flush with the dikes.
4. Lugs shall be fabricated from gold plated wire with a nominal diameter of 0.050 inch.
The outside diameter of the lugs shall be 3/16 inch + 1/64 inch. Lugs shall be hard
soldered to the pendant or bar 19/32 inch + 1/64 inch on centers. As an alternate method,
lugs may be cut into the working die.
5. Two brass balls 0.105 inch in diameter shall be soldered to the sides of the
suspension bar as shown. As an alternate method, the balls may be an integral part of the
suspension bar and may be cut into the contractor's working die.
6. Links (jump rings) shall be fabricated from gold plated wire with a nominal diameter of
0.050 inch. The links shall have an outside diameter of 3/16 inch + 1/32 inch - 0 inch.
7. Target shall be superimposed on the pendant and shall be secured by means of two
solid brass rivets.
8. The attaching device shall be prong and clutch type. The prongs shall be located on
the horizontal center line of the bar equidistant from each end and 1-5/16 inches
+ 1/64 inch apart.
9. A forcer may be used to bring up the design of the shield on the suspension bar.
Page 2 of 3
