INCH-POUND
MIL-DTL-3628/263
15 September 2014
DETAIL SPECIFICATION SHEET
BELT BUCKLE, HAP ARNOLD STAR DEVICE FOR GENERAL OFFICER, U.S. AIR FORCE
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification
sheet and the latest issue of MIL-DTL-3628.
DASH NO.
-1: Male
-2: Female
MATERIAL: Red Brass 85/15 (UNS Alloy No. C-230)
FINISH: (For buckle and star attachment device): Nickel Plated, Mirror-like Polished and
shall match The Institute of Heraldry (TIOH) Metal Finish Chip Number 16.
DIMENSIONS:
HEIGHT:
-1: 1-7/32 inches (REF)
-2: 1-1/32 inches (REF
WIDTH:
-1: 1-5/32 inches (REF)
-2: 31/32 inch (REF)
THICKNESS:
-1 and -2: 0.070 inch + 0.010 inch
ATTACHING DEVICE: The device shall be secured to the background by two solid brass rivets,
should be located along a horizontal center line and shall be dapped to insure a snug fit. The
device shall be pierced as shown.
AMSC N/A
Page 1 of 2
FSC 8455
