INCH-POUND
MIL-DTL-3476/37C
28 April 2014
SUPERSEDING
MIL-DTL-3476/37B
20 August 1997
DETAIL SPECIFICATION SHEET
BRASSARD, AMVER BOARDING OFFICER, U.S. COAST GUARD
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and MIL-DTL-3476
MATERIAL:
BASE: Gabardine; Wool Polyester and Wool
DEVICE: Rayon Embroidery on Base Cloth
COLOR:
BASE: Dark Blue (Shade 3362)
DEVICE: White HA 67101
Flag Blue HY 67124
CONSTRUCTION DETAILS:
1.
The device shall be Schiffli embroidered on the face of the gabardine cloth in the direction of the twill line
in accordance with Cartoon No. A-1-472 using 100/2 ply denier (see The Institute of Heraldry Drawing
Number B-8-62). The device shall be embroidered using a 12/4 span and a minimum of 9805 stitches
2. The embroidered device shall be left intact on a single thickness of cloth. Hemming shall be
accomplished using Stitch Type EFa-1 with 12 stitches to the inch.
3. The thread for hemming shall conform to Type IC2, 3 Ply, Ticket No. A of A-A-52094
AMSC N/A
Page 1 of 2
FSC 8455
