INCH-POUND
MIL-DTL-3476/30D
21 April 2014
SUPERSEDING
MIL-DTL-3476/30C
20 August 1997
DETAIL SPECIFICATION SHEET
BRASSARD, TRAINEES OR CANDIDATES ACTING AS NON-COMMISSIONED
OFFICER AT TRAINING SCHOOL OR CENTER, SERGEANT, U.S. ARMY
This specification is approved for use by all
Departments and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall consist of this specification sheet
and MIL-DTL-3476.
MATERIAL:
BASE: Melton Cloth
DEVICE: Uniformed Twill (Embroidered)
COLOR:
BASE: Blue (Shade 3313 or 3346)
DEVICE:
BACKGROUND: Dark Blue (Cable 65012)
CHEVRONS: Golden Light (Cable HG 67107)
CONSTRUCTION DETAILS:
1. The device shall be embroidered in accordance with the cartoon for sergeant (Cartoon No. B-
3-15-M) The size of the embroidery yarn and number of stitches shall be as specified on the
cartoon.
2. The device shall be appliquéd to the base in the position shown using Stitch Type 301 with 12
stitches to the inch (see The Institute of Heraldry Drawing Number B-8-41).
3. The thread for appliquéing shall conform to Type IC2, 3 Ply, Ticket No. A of A-A-52094 The
color of the thread shall conform to Flag Blue Cable No. HY 67126
AMSC N/A
Page 1 of 2
FSC 8455
